IN STOCK

The Draco Centre Diff Set 2024 has bottom access to your centre diff and is made of 7075-T6 aluminum with a hard anodized coating! There are also extra mounting holes which raises the set +5mm increasing ground clearance and reducing the risk of hitting the gear.

The set includes the new 52T Draco Spur Gear (previously a 56T Spur Gear) which improves clearance while still maintaining a lower CG and giving you a wide range of pinion options from 11T to 20T pinions.

The Draco Centre Diff Set can be used as an upgrade for your pre 2017 Savage Flux/Savage Flux XL and as an electric conversion for the Savage X and XL.

The Draco CDS 2024 can be ordered as one set or as a bundle with the Draco Diff Case. Be sure to check out the 52T Spur gear and outdrives which can be ordered as spares (only for this set).

Please note colour of the product and the laser etching is subject to change

Compatibility:

• HPI Savage Flux HP (pre2017 series)

• HPI Savage Flux XL (pre2017 series)

• HPI Super 5SC Flux

• HPI Savage X SS (Nitro to Electric Conversion)

• HPI Savage X (Nitro to Electric Conversion)

• HPI Savage XL (Nitro to Electric Conversion)

• 2022 HPI Savage X 4.6 (Nitro to Electric Conversion)

• 2022 HPI Savage XL 5.9 (Nitro to Electric Conversion)

• HPI Savage .21/.25/SS (Nitro to Electric Conversion)

NOT COMPATIBLE WITH THE FOLLOWING:

• 2017+ HPI Savage Models (GTXL-1 etc)

• HPI Savage Octane

• 2022 HPI Savage X Flux (GTXL-6)

• 2022 HPI Savage XL Flux (GTXL-6)

Features:

• CNC Machined 7075-T6 Aluminum Plates

• Hard Anodized for wear resistance and strength

• Bottom-access to Centre Differential

• Uses stock dogbones (no custom dogbones necessary)

• Centre Diff Set accepts larger can motors (up to Hobbywing 4985 and Castle Creations 1717)

• Includes Custom Draco Outdrives with bearing support

• Includes Custom Draco Mod 1 52T Spur Gear

• Compatible with HPI Stock diffs, shafts, cup joints and centre dogbones

• Draco Diff Case compatible

• ESC Mount included

• FIts most 6S capable Motors and ESCs

• Fits only motors with 25mm screw pattern and M4 screws only (M3 screws cannot be used)

• Please note colour of finish and laser etching is subject to change

• NOT SUITABLE FOR 8S Systems (Castle 2028 Series Motors/Hobbywing 5685 motors and larger and Castle XLX2 or Hobbywing Max 5/Max 4 ESCs)

Check out the options and prices below:

All prices are in US Dollars and shipping will be added in the check-out.

If you have any questions, please get in touch here: Contact Draco Precision

Option 1: Draco Centre Diff Set 2024 only

TOTAL - $125

Option 2: Draco Centre Diff Set 2024 with Pre-Assembled Draco Centre Differential and 500,000cst Silicone Oil

TOTAL - $169

Option 3: Draco Centre Diff Set 2024 with Pre-Assembled Draco Centre Differential and 1,000,000cst Silicone Oil

TOTAL - $169

Shipping is added in checkout.
